Type1510 16g 2200KV ブラシレスモーター

小型機用ブラシレスモーター　全備重量150ｇ程度用


仕様

KV：2200

Dimension：Φ18mm x 17.5mm (excluding shaft)

Weight：16.1g/0.57oz (not including connectors)

Diameter of shaft：Φ2mm

Length of front shaft：8mm

Resistance: 0.52 Ω

Max efficiency currency: 2A to 6A, >70%

Max working currency: 8.5A

IO: 0.5A/10V

使用例
Prop recommendation:
3S/10V, GWS 5030HD, 16500RPM, 5.5A, thrust 272g
2S/7V, GWS 7035HD, 10150RPM, 5.6A, thrust 215g
